| On-Site | Accredited* | |
|---|---|---|
| Angle | ||
| Angle block | ||
| Chamfer gauge | ||
| Inclinometer | ||
| Level | ||
| Protractor | ||
| Sine bar | ||
| Square | ||
| Transit / laser level | ||
| CMM | ||
| Coordinate Measuring Machine | ||
| Diameter | ||
| Bore gauge | ||
| Cylindrical plug gauge | ||
| Flat plug gauge | ||
| Master disc | ||
| Pi tape | ||
| Pin gauge | ||
| Plain taper plug | ||
| Radius gauge | ||
| Section Surfaces | ||
| Coating thickness gauge | ||
| Parallels | ||
| Roughness tester | ||
| Surface plate | ||
| V block | ||
| Distance | ||
| Blocks | ||
| Cable length | ||
| Caliper | ||
| Counter sink gauge | ||
| Crimpers | ||
| Depth gauge | ||
| Feeler gauge | ||
| Flushness gauge | ||
| Footage counter | ||
| Gauge block | ||
| Glass scale | ||
| Height gauge | ||
| Height set masters | ||
| Indicator | ||
| Metal detector | ||
| Micrometers | ||
| Microscopes | ||
| Mikemaster | ||
| Optical comparator | ||
| Profile projector | ||
| Ruler | ||
| Snap gauge | ||
| Step block | ||
| String potentiometer | ||
| Supermicrometer | ||
| Tape measure | ||
| Thickness gauge | ||
| Torque arm | ||
| Threads | ||
| Plug gauge | ||
| Profile gauge | ||
| Ring gauge | ||
| Thread & gear wires | ||
DIMENSIONAL CALIBRATION SERVICES
Precision dimensional calibration on your terms.
Stay compliant and audit-ready without the hassle.
Dimensional Measurement
Aldinger calibrates a wide array of equipment used to measure physical and/or dimensional attributes with accuracy and precision, even up to one millionth (1/1000000) of an inch on certain equipment.
Asset tracking
Aldinger’s services and complimentary asset tracking solutions are designed to eliminate these pain points, allowing your team to focus on what they do best.
Dimensional Calibration Service Overview
Aldinger technicians can calibrate your equipment for accuracy to one millionth (1/1000000) of an inch on certain equipment.
* Aldinger is accredited by A2LA to ISO/IEC 17025 standards
Scope of accreditation to ISO/IEC 17025:2017 & ANSI/NCSL Z540-1-1994
Aldinger Company
1440 Prudential Drive | Dallas, TX 75235
Dustin Detten | Phone: 214-638-1808
Valid to: June 30, 2026
Certificate number: 1509.01
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Calipers | |||
Up to 24 in (24 to 48) in |
550 μin 1100 μin |
Gauge blocks (field) |
|
Up to 48 in (48 to 96) in |
61 μin 1500 μin |
Gauge blocks (field) Gauge blocks (lab) |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Dial & test indicators | |||
Up to 1 in Up to 3in |
20 μin 99 μin |
Gauge blocks (lab), Gauge blocks, ULM, SuperMic (lab) |
|
Up to 3 in |
90 μin |
Gauge blocks (field) |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Gauge blocks | |||
Up to 1 in 2-4 in |
(3.3 + 1.5L) μin (7.7 + 1.5L) μin |
Master gage block set, Federal 130B-24 comparator |
|
(4 to 20) in |
(7 + 2L) μin |
Master gauge block set, ULM |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Angle blocks | |||
(0 to 90)° |
0.005° |
Sine bar & gauge blocks |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Squares | |||
Up to 18 in |
99 μin |
Master square, amplified gauge head |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Height gauges | |||
Up to 48 in |
280 μin 89 μin |
Gauge blocks (field) Gauge blocks (lab) |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Length standards | |||
Up to 18 in Up to 48 in |
(37 + 1.5L) μin (65 + 1.5L) μin |
ULM / SuperMic10, gauge blocks |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Levels | |||
Up to 12 in |
(40 + 14L) μin |
Surface plate, granite square |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Micrometers | |||
Up to 4 in (4 to 24) in (24 to 48) in |
33 μin 550 μin 1100 μin |
Gauge blocks (field) |
|
Up to 4 in (4 to 24) in (24 to 96) in |
15 μin 60 μin 1500 μin |
Gauge blocks (lab) |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Plain ring gauges | |||
(0.125 to 12) in |
(22 + 1.5L) μin |
ULM, gauge blocks |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Protractors | |||
(0 to 90)° |
0.049° |
Surface plate, angle blocks, sine bar w/gauge blocks |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Thread plugs | |||
| Pitch Diameter | (0.040 to 4) in (4 to 12) in |
(71 + 1.5L) μin (94 + 1.5L) μin |
Three-wire method, direct measure |
| Major diameter | (0.040 to 4) in (4 to 12) in |
(19 + 1.5L) μin (35 + 1.5L) μin |
Three-wire method, direct measure |
| Pitch diameter (taper) | (0.040 to 4) in (4 to 12) in |
(77 + 1.5L) μin |
Three-wire method, direct measure |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Adjustable thread rings | |||
Up to 3.125 in |
(W) Master plug tolerance |
Set using master plug gages. ASME/ANSI B1.2-1983 and ASME/ANSI B1.3-2007 |
|
| Taper thread rings – pitch diameter | Up to 3 in |
120 μin |
Two-wire method, direct measure |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Thread wires | |||
(4 to 80) TPI |
(11 + 1.5L) μin |
Master thread wire set |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Surface plates- flatness and repeatability | |||
Up to 107 in DL |
(48 + 0.41DL) μin |
Leveling system (DL is diagonal of the plate) |
|
| Indicator stands | (-0.002 to 0.002) in |
31 μin |
Repeat reading gauge |
(-0.002 to 0.002) in |
45 μin |
Repeat reading gauge, triangular gauge block base |
|
(-0.01 to 0.01) in |
580 μin |
Indicator, triangular gauge block base |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Optical comparators | |||
| X-axis | Up to 12 in |
(250 + 91L) μin |
Glass scale |
| Y-axis | (0.040 to 4) in |
(250 + 91L) μin |
Glass scale |
| Angle | (0 to 90)° |
0.029° |
Angle blocks |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Rulers | |||
Up to 72 in |
0.013 in |
Standard ruler |
|
| Tape measures | Up to 40 in Up to 100 ft |
0.013 in 0.062 in |
Standard ruler Standard tape |
| Pi tapes | Up to 72 in |
910 μin |
Gauge blocks |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Radius gauges | |||
Up to 0.75 in |
1300 μin |
Optical comparator and overlay |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Angle gauges | |||
Up to 180° |
0.044° |
Optical comparator and vernier |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Torque arms | |||
Up to 24 in |
0.0047 in |
Height gauge, test indicator |
|
Up to 48 in |
0.003 in |
Gauge blocks |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Coating / Electromagnetic thickness | |||
Up to 120 mils |
0.25 mils |
Shims |
|
Calibration Without the Complexity
Calibration and regulatory compliance can be frustrating and expose you to the risks of production downtime and failed audits. You need a trusted partner who makes the process simple and something you barely have to think about.
Get fast, reliable calibration services that keep you audit-ready and in control.
- Accurate, certified calibration
- Fast turnaround times
- Clear documentation for compliance
