ELECTRICAL CALIBRATION SERVICES
Reliable electrical calibration, tailored to your schedule.
Stay compliant and always audit-ready without the stress.
Electrical Measurement
Ranging from the simple amp/volt meter to more advanced equipment, timely calibration by an Aldinger technician will help ensure your electronic measuring equipment is always precise and accurate.
Asset tracking
Aldinger’s services and complimentary asset tracking solutions are designed to eliminate these pain points, allowing your team to focus on what they do best.
Electrical Calibration Service Overview
Browse the list below for a brief overview of some of the equipment we calibrate or, for a detailed list, see our scope.
* Aldinger is accredited by A2LA to ISO/IEC 17025 standards
Scope of accreditation to ISO/IEC 17025:2017 & ANSI/NCSL Z540-1-1994
Aldinger Company
1440 Prudential Drive | Dallas, TX 75235
Dustin Detten | Phone: 214-638-1808
Valid to: June 30, 2026
Certificate number: 1509.01
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| AC current- Measure | |||
| Up to 1 A | 60 Hz to 1 kHz |
0.16 % + 0.4 mA |
HP 34401 |
| (1 to 3) A | 60 Hz to 1 kHz |
0.14 % + 1.8 mA |
HP 34401 |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| AC current- Generate | |||
| (29 to 330) μA | 45 Hz to 1 kHz |
0.13 % + 0.1 μA |
Fluke 5522A |
| 330 μA to 3.3 mA | 45 Hz to 1 kHz |
0.10 % + 0.15 μA |
Fluke 5522A |
| (3.3 to 33) mA | 45 Hz to 1 kHz |
0.07 % + 2 μA |
Fluke 5522A |
| (33 to 330) mA | 45 Hz to 1 kHz |
0.083 % + 20 μA |
Fluke 5522A |
| (0.33 to 3) A | 45 Hz to 1 kHz |
0.10 % + 100 μA |
Fluke 5522A |
| (3 to 10) A | 45 Hz to 1 kHz |
0.21 % + 2 mA |
Fluke 5522A |
| (10 to 20) A | 45 Hz to 1 kHz |
0.21 % + 5 mA |
Fluke 5522A |
| (16 to 150) A | (45 to 440) Hz |
0.14 % + 0.25 A |
Using 50 turn coil |
| (150 to 1000) A | (45 to 440) Hz |
0.14 % + 0.9 A |
Using 50 turn coil |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| AC voltage- Generate | |||
| (1 to 330) mV | 45 Hz to 10 kHz |
0.018 % + 8 μV |
Fluke 5522A |
| (0.330 to 3.3) V | 45 Hz to 10 kHz |
0.018 % + 60 μV |
Fluke 5522A |
| (3.3 to 33) V | 45 Hz to 10 kHz |
0.017 % + 0.6 mV |
Fluke 5522A |
| (33 to 330) V | 45 Hz to 10 kHz (1 to 10) kHz |
0.023 % + 2 mV 0.023 % + 6 mV |
Fluke 5522A |
| (330 to 1020) V | 45 Hz to 10 kHz (1 to 5) kHz |
0.046 % + 10 mV 0.046 % + 10 mV |
Fluke 5522A |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| AC voltage- Measure | |||
| Up to 100 mV | 60 Hz to 3 kHz |
0.063 % + 40 μV |
HP 34401 |
| 100 mV to 1 V | 60 Hz to 3 kHz |
0.063 % + 300 μV |
HP 34401 |
| (1 to 10) V | 60 Hz to 3 kHz |
0.062 % + 3 mV |
HP 34401 |
| (10 to 100) V | 60 Hz to 3 kHz |
0.064 % + 30 mV |
HP 34401 |
| (100 to 750) V | 60 Hz to 3 kHz |
0.075 % + 230 mV |
HP 34401 |
| Up to 10 kV | 60 Hz to 3 kHz |
0.14 % + 100 mV |
Vitrek 4700 w/ HVL-70 |
| Up to 50 kV | 60 Hz to 3 kHz |
0.1 % + 400 mV |
Vitrek 4700 w/ HVL-70 |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Capacitance – Generate | |||
| Low | (0.22 to 3.3) nF (3.3 to 33) nF (33 to 330) nF (330 to 3300) nF |
0.5 % + 10 pF 0.26 % + 100 pF 0.26 % + 300 pF 0.26 % + 3 nF |
Fluke 5522A |
| High | (3.3 to 33) μF (33 to 330) nF (330 to 3300) nF (3.3 to 110) mF |
0.4 % + 30 nF 0.45 % + 300 nF 0.45 % + 3 μF 1.1 % + 10 μF |
Fluke 5522A |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| DC Current – Generate | |||
(0 to 330) μA Up to 3.3 mA Up to 33 mA Up to 330 mA Up to 3 A (1.1 to 11) A (11 to 20.5) A |
0.015 % + 20 nA 0.010 % + 50 nA 0.014 % + 250 nA 0.010 % + 2.5 μA 0.038 % + 40 μA 0.050 % + 500 μA 0.1 % + 750 μA |
Gauge blocks (field) |
|
(10 to 150) A (150 to 1000) A |
0.5 % + 0.14 A 0.5 % + 0.5 A |
Gauge blocks (lab) |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| DC Current – Measure | |||
Up to 10 mA (10 to 100) mA 100 mA to 1 A (1 to 3) A |
0.075 % + 6 μA 0.051 % + 5 μA 0.11 % + 100 μA 0.13 % + 600 μA |
HP 34401 |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| DC Voltage – Generate | |||
(0 to 330) mV Up to 3.3 V Up to 33 V (30 to 330) V (100 to 1000) V |
0.002 % + 1 μV 0.0012 % + 2 μV 0.0013 % + 20 μV 0.0018 % + 0.15 mV 0.0019 % + 1.5 mV |
Fluke 5522A |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| DC Voltage – Measure | |||
Up to 100 mV 100 mV to 1 V (1 to 10) V (10 to 100) V (100 to 1000) V |
0.0054 % + 3.5 μV 0.0042 % + 7 μV 0.0037 % + 50 μV 0.0048 % + 600 μV 0.0049 % + 10 mV |
HP 34401 |
|
Up to 10 kV Up to 70 kV |
0.071 % + 30 mV 0.049 % + 200 mV |
Vitrek 4700 w/ HVL-70 |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Oscilloscopes - Square wave amplitude | |||
| 50 Ω at 1 kHz | 1 mV to 6.6 V pk-pk |
0.34 % + 40 μV |
Fluke 5522A SC1100 |
| 1 MΩ at 1 kHz | 1 mV to 130 V pk-pk |
0.25 % + 40 μV |
Fluke 5522A SC1100 |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| Oscilloscopes - DC voltage amplitude | |||
| 50 Ω Load | (0 to ± 6.6) V |
0.25 % + 40 μV |
Fluke 5522A SC1100 |
| 1 MΩ load | (0 to ± 130) V |
0.05 % + 40 μV |
Fluke 5522A SC1100 |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| Oscilloscopes - Level sine wave | |||
| Frequency | Up to 1100 MHz |
2.5 parts × 10 |
Fluke 5522A SC1100 |
| Amplitude | 50 kHz Reference 50 kHz to 100 MHz (100 to 300) MHz (300 to 600) MHz (600 to 1100) MHz |
2.8 % + 300 μV 4.2 % + 300 μV 4.6 % + 300 μV 6.4 % + 300 μV 7.4 % + 300 μV |
Fluke 5522A SC1100 |
| Flatness | 50 kHz to 100 MHz (100 to 300) MHz (300 to 600) MHz (600 to 1100) MHz |
2.7 % + 100 μV 3.0 % + 100 μV 4.6 % + 100 μV 5.5 % + 100 μV |
Fluke 5522A SC1100 |
| Frequency | CMC (±) | Comments | |
|---|---|---|---|
| Oscilloscopes - Time markers | |||
| 50 Ω Load | 5 s to 50 ms 20 ms to 1 ns |
28 + 1000t μs/s 3.2 μs/s |
t = time in seconds |
| Rise time - Generate | 1 kHz to 2 MHz (200 to 300) ps |
120 ps |
t = time in seconds |
(2 to 10) MHz (200 to 300) ps |
120 ps |
||
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Electrical calibration of temperature controllers | |||
(-200 to 1371) °C |
0.56 °C |
Omega CL27 - Type K |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Resistance – Generate | |||
(0 to 330) Ω (330 to 3300) Ω (3300 to 33 000) Ω (33 to 330) kΩ (330 to 3300) kΩ (3.3 to 33) MΩ (33 to 110) MΩ (110 to 330) MΩ (330 to 1100) MΩ |
0.065 % + 20 mΩ 0.029 % + 100 mΩ 0.029 % + 1.0 Ω 0.0037 % + 10 Ω 0.0063 % + 150 Ω 0.026 % + 2500 Ω 0.063 % + 3.0 kΩ 0.065 % + 100 kΩ 0.065 % + 500 kΩ |
Fluke 5522A |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Resistance – Measure | |||
Up to 100 Ω 100 Ω to 1 kΩ (1 to 10) kΩ (10 to 100) kΩ 100 kΩ to 1 MΩ (1 to 10) MΩ (10 to 100) MΩ |
0.066 % + 4 mΩ 0.031 % + 10 mΩ 0.031 % + 100 mΩ 0.011 % + 1 Ω 0.012 % + 10 Ω 0.048 % + 100 Ω 0.08 % + 10 kΩ |
HP 34401 |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Electrical simulation of RTD | |||
| PT385, 100 Ω | (-200 to 0) °C (0 to 100) °C (100 to 400) °C (400 to 630) °C (630 to 800) °C |
0.058 °C 0.17 °C 0.12 °C 0.14 °C 0.28 °C |
Fluke 5522A |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Electrical simulation of thermocouples and indicators | |||
| Type E | (-250 to -100) °C (-100 to -25) °C (-25 to 350) °C (350 to 650) °C (650 to 1000) °C |
0.51 °C 0.16 °C 0.19 °C 0.20 °C 0.24 °C |
Fluke 5522A |
| Type J | (-210 to -100) °C (-100 to -30) °C (-30 to 150) °C (150 to 760) °C (760 to 1200) °C |
0.28 °C 0.16 °C 0.14 °C 0.17 °C 0.23 °C |
Fluke 5522A |
| Type K | (-200 to -100) °C (-100 to -25) °C (-25 to 120) °C (120 to 1000) °C (1000 to 1372) °C |
0.33 °C 0.18 °C 0.20 °C 0.24 °C 0.40 °C |
Fluke 5522A |
| Type T | (-250 to -150) °C (-150 to 0.0) °C (0.0 to 120) °C (120 to 400) °C |
0.63 °C 0.24 °C 0.16 °C 0.14 °C |
Fluke 5522A |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Welding devices | |||
(0 to 350) Amps DC (0 to 100) Volts DC (100 to 700) Feed Rate IPM |
0.87 ADC 0.012 VDC 3.6 IPM |
Load bank, current shunt, DMM |
|
Let’s Get You Audit-Ready
Quality managers, engineers, and industry professionals trust Aldinger for precise, accredited calibration. We ensure your equipment is compliant, reliable, and ready for whatever comes next.
