FORCE CALIBRATION SERVICES
Stay compliant and audit-ready with expert force calibration services that fit your schedule.
Force Measurement
Whether proof load testing or calibrating, Aldinger can apply tension or compression and calibrate up to 100,000 pounds (lbs).
Asset tracking
Aldinger’s services and complimentary asset tracking solutions are designed to eliminate these pain points, allowing your team to focus on what they do best.
Force Calibration Service Overview
Aldinger technicians can calibrate your force measurement equipment up to 100,000 pounds (lbs).
* Aldinger is accredited by A2LA to ISO/IEC 17025 standards
Scope of accreditation to ISO/IEC 17025:2017 & ANSI/NCSL Z540-1-1994
Aldinger Company
1440 Prudential Drive | Dallas, TX 75235
Dustin Detten | Phone: 214-638-1808
Valid to: June 30, 2026
Certificate number: 1509.01
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Accelerometers | |||
(5 to 9) Hz (10 to 99) Hz (100 to 1999) Hz (2000 to 10 000) Hz (10 001 to 15 000) Hz |
2.1 % 1.3 % 1.5 % 2.0 % 2.5 % |
Back to back comparison |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Balances | |||
(0 to 20) g (0 to 200) g |
0.11 mg 0.69 mg |
Class 1 weights |
|
0 to 200) g (0 to 1000) g (0 to 5000) g |
1.3 mg 6.6 mg 34 mg |
Class 2 weights |
|
(0 to 20) g (0 to 200) g (0 to 1000) g (0 to 5000) g (0 to 10 000) g (0 to 20 000) g |
0.81 mg 4.8 mg 24 mg 130 mg 370 mg 460 mg |
Class 4 weights |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Force - Measuring equipment | |||
| Tension / Compression | Up to 100 lbf |
0.0064 lbf |
Class F weights w/ load cells |
| Compression | (100 to 1000) lbf (1000 to 10 000) lbf (10 000 to 50 000) lbf (10 000 to 100 000) lbf (50 000 to 500 000) lbf |
0.26 % Indication 0.24 % Indication 0.33 % Indication 1.6 % Indication 0.4 % Indication |
Class F weights w/ load cells |
| Tension | (100 to 1000) lbf (1000 to 10 000) lbf (10 000 to 50 000) lbf |
0.23 % Indication 0.23 % Indication 0.29 % Indication |
Class F weights w/ load cells |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Mass, fixed points | |||
1 mg 2 mg 5 mg 10 mg 20 mg 30 mg 50 mg 100 mg 200 mg 300 mg 500 mg 1 g 2 g 5 g 10 g 20 g 50 g 100 g 200 g |
2.2 μg 2.1 μg 2.9 μg 1.4 μg 1.5 μg 2.2 μg 1.6 μg 1.7 μg 1.6 μg 1.6 μg 2.1 μg 11 μg 3.3 μg 5.7 μg 7.2 μg 13 μg 11 μg 39 μg 140 μg |
Modified double substitution |
|
500 g 1 kg 2 kg 5 kg |
320 μg 390 μg 1.7 mg 2.6 mg |
Direct comparison |
|
10 kg 20kg |
93 mg 94mg |
||
0.8859 g (1/32 oz) 1.772 g (1/16 oz) 3.544 g (1/8 oz) 7.087 g (1/4 oz) 14.17 g (1/2 oz) 28.35 g (1 oz) 56.7 g (2 oz) 113.4 g (4 oz) 226.8 g (8 oz) |
12 μg 94 μg 240 μg 170 μg 170 μg 370 μg 150 μg 740 μg 5.1 mg |
||
0.4536 g (0.001 lb) 0.9072 g (0.002 lb) 2.27 g (0.005 lb) 4.54 g (0.01 lb) 9.07 g (0.02 lb) 22.68 g (0.05 lb) 45.36 g (0.1 lb) 90.72 g (0.2 lb) |
130 μg 56 μg 26 μg 16 μg 56 μg 79 μg 37 μg 87 μg |
||
453.6 g (1 lb) 907.2 g (2 lb) 2267.96 g (5 lb) 4535.8 g (10 lb) 9071.8 g (20 lb) 22 679.62 g (50 lb) 45 359.237 g (100 lb) 90 718.475 g (200 lb) 226 796.185 g (500 lb) 453 592.37 g (1000 lb) |
3.8 mg 7.9 mg 8.3 mg 7.4 mg 94 mg 95 mg 0.43 g 0.43 g 0.45 g 0.47 g |
||
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Optical tachometer | |||
200 FPM 3000 FPM 29 999 FPM |
1.3 FPM 1.7 FPM 3.9 FPM |
Calibrated strobe |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Pressure measuring equipment - Gauges, transducers and transmitters | |||
(0 to 30 000) psig |
43 psig |
Additel digital test gauge |
|
(0 to 10 000) psig (0 to 3000) psig |
12 psig 3.8 psig |
Crystal XP2 digital test gauge |
|
(0 to 5000) psig (0 to 300) psig |
3.9 psig 0.18 psig |
Druck/Martel transducer |
|
(0 to 2) in H2O |
0.0026 in H2O |
Dwyer hook gauge |
|
(0 to 300) psig (0 to 3000) psig (0 to 10 000) psig |
0.051 psig 0.4 psig 1.3 psig |
GE/Pace 1003 |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Scales | |||
(0 to 10) lb (0 to 20) lb |
0.000 25 lb 0.000 25 lb |
Class 4 weights |
|
(0 to 10) lb (0 to 100) lb (0 to 200) lb (0 to 500) lb (0 to 1000) lb (0 to 5000) lb (0 to 20 000) lb |
0.0063 lb 0.0063 lb 0.0064 lb 0.0064 lb 0.18 lb 0.19 lb 0.21 lb |
Class 5 weights |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Torque wrenches - Measure | |||
(10 to 50) in⋅lbf (30 to 400) in⋅lbf (80 to 1000) in⋅lbf (240 to 3000) in⋅lbf |
0.17 in⋅lbf 1.8 in⋅lbf 5.1 in⋅lbf 21 in⋅lbf |
CDI/Norbar torque calibrator |
|
(1200 to 6000) in⋅lbf (2400 to 12 000) in⋅lbf |
23 in⋅lbf 58 in⋅lbf |
Norbar torque calibrator |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Torque measuring equipment - Transducers | |||
Up to 200 in⋅lbf Up to 1200 in⋅lbf Up to 12 000 in⋅lbf |
0.10 % 0.091 % 0.10 % |
Torque arm and weights |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Vacuum measuring equipment - Gauges | |||
(0 to 15) psig |
0.03 psig |
Druck DPI 610 |
|
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Rotations speed - Measurement | |||
| Contact | Up to 200 RPM (200 to 3000) RPM (3000 to 20 000) RPM |
1.5 RPM 2.4 RPM 11 RPM |
Monarch PLT200 |
| Optical | Up to 200 RPM (3000 to 30 000) RPM |
1.3 RPM 3.3 RPM |
Monarch PLT200 |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Indirect verification of Rockwell hardness testers | |||
| HRB | Low Medium High |
1.0 HRB 0.65 HRB 0.49 HRB |
Indirect verification |
| HRC | Low Medium High |
0.45 HRC 0.36 HRC 0.37 HRC |
Indirect verification |
| Range | CMC (±) | Comments | |
|---|---|---|---|
| Indirect verification of Brinell hardness testers | |||
| HBW 10/500 | Low |
4.0 HBW |
Indirect verification |
| HBW 10/3000 | High |
4.8 HBW |
Indirect verification |
Don't see exactly what you're looking for?
Our calibration specialists are here to help. We’ll assess your measurement equipment—even unique or highly specialized tools—to determine the best calibration solution for you.
